Rigol Ds1052E 50Mhz Band Widths 2-Channel Digital Sss
Kami Menyediakan Berbagai Macam Barang Berkualitas
– Item Selalu Tersedia
– Pengiriman Pat
– Hub Kami Untuk Menanyakan Varian Barang
Brand Name : Rigol
Diy Supplies : Ectrical
Display Size : 5.0 – 6.9 Inches
Is Battery Demountab : No
Display Resolution : 640*480 Pixels
Digital Channels : 2
Model Number : Ds1052E
Real Time Sling Rate : 1Gsa/S
Record Ngth : 1M
Band Width : Ss Than 60Mhz
Iscustomized : Yes
Application :
1. Design And Debug
2. Manufacturing
3. Education & Training
4. Servi & Maintenan
Technical Specifications:
Ds1052E Digital Oscilloscope Performan Parameters:
Bandwidth
50 Mhz
Memory Depth
Sing Channel: 1M; Doub Channels: 500K
Channels
2
Real-Time S Rate
Sing Channel: 1 Gsa/S; Doub Channels: 500Msa/S
Equivant S Rate
10Gsa/S
Rise Time
1.2 Ns
Input Impedan
1 M || 15 Pf,50
Sec/Div Ran
2 Ns/Div- 50 S/Div
Lissajous Figures
Bandwidth
50 Mhz
Phase Differen
? 3?
Trigr Modes
Ed, Pulse, Video, Slope, Delay
Trigr Sour
Ch1,Ch2,Ext,Ext/5,Ac
Vertical Sensitivity
2 Mv/Div-10 V/Div
Vertical Resolution
8Bit
Input Coupling
Dc, Ac, Gnd
Input Max Volta
300 V (Dc + Ac Vpp)
Scroll Ran
Ms/Div – 50 S/Div
Cursor Measure
Manual, Track, Auto
Math
+,-,?,Fft
Stora
Built-In: 10 Gro Waveforms, 10 Gro Set Up ; Usb: Bitmap Memory, Csv Stora, Wave Set Up
Interfa
Usb Devi,Usb Host,Rs-232,P/F Out (Isolated)
Display
64K Tft Color Lcd (320 X 234)
Display Langua
Multilingual User Interfa
Power Sour Volta
100-240V Ac/ 50W Max
Size
303Mm?154Mm?133Mm(L?H?W)
Weight
Approximately 2.4 Kg
Packa Include:
1 X Digital Oscilloscope
1 X Power Cord
2 X Probe
1 X
